Description
Sell CNC 4-6 axis Welding Controller.
The product is the most advanced robot control system for right-angle robot and research and development, the main sales of two-axis / three-axis / four-axis / five-axis / six-axis control system to provide Chinese and English switching function.
Electronic touch screen, multi-axis control, comes with analog output function (0-10V two output)
Control system parameters
- Number of motor shafts: 4 axes, 6 axes
- Motor type: stepper motor, incremental servo motor, absolute value of the servo motor
- Pulse frequency: 2000K
- IO input: 24 “NPN open collector” (optocoupler isolation)
- IO output: 16 “NPN open collector” (optocoupler isolation)
- Display: 7-inch resistive touch screen
- Storage capacity: 8M electronic hard drive + SD card expansion
- Operation: key + joystick + touch screen
- Control voltage: DC12-24V
- Operating temperature: -20 to 50 ° C
Control system function
- Using teaching programming, programming is convenient and flexible, easy to learn and use
- You can edit any trajectory in space
- The IO port can be edited and defined
- There are four groups of switches, different start switches can call different programs
5.4 Group start switch has a reservation function, reducing the operation waiting time
- There are welding-specific IO port, in the run track automatically open the torch, greatly reducing the programming time
- Teaching position using rocker operation, speed stepless transformation, teaching location is very convenient
- With gunpoint automatic compensation function, just teach two points, the gun tip can automatically compensate
- Have “reference point function”, replace the welding gun or replace the fixture only need to modify the reference point without re-programming
- Support arc test, arc automatic stop function
Note: The welder is required to have a successful arc signal or an optional arc detection sensor
- Different track speed can be set separately to facilitate the adjustment of the welding process
- Different traces of welding current, voltage can be set separately
- Weld gun welding function, welding width and length can be set
